Typus et nomen funis

Nominal Cross-Sectional Area ㎡	Insulation crassitudine mm	YJV YJY YJLV YJLY			YJV22 YJV22 YJLV23 YJLV2 3			YIV32 YV32 YLV32 YILV32
		Proxime altiore diametri mm	Pondere computatum funem		Proxime altiore diametri mm	Pondere computatum funem		Proxime altiore diametri mm	Pondere computatum funem
		Proxime altiore diametri mm	YJV YJY	YJLV YJLY	Proxime altiore diametri mm	YJV22 YJV22	YJLV23 YJLV23	Proxime altiore diametri mm	YJLV23 YJLV23	YJLV32 YJLV32
1×25	3.4	19.2	560	一	23.2	839		25.2	935	一
1×35	3.4	20.3	678	一	24.3	970		26.3	1069	一
1×50	3.4	21.5	818	529	25.5	1127	838	27.5	1229	940
1×70	3.4	23.3	1056	637	27.1	1375	956	29.3	1495	1076
1×95	3.4	25.2	1342	762	29.0	1685	1105	31.2	1818	1238
1×120	3.4	26.4	1587	859	30.2	1946	1218	32.4	2081	1353
1×150	3.4	28.2	1887	988	32.0	2269	1370	34.2	2412	1513
1×185	3.4	29.8	2251	1130	33.6	2652	1531	35.8	2801	1680
1×240	3.4	32.4	2827	1359	37.6	3610	2142	38.4	3425	1957
1×300	3.4	34.9	3447	1602	39.9	4269	2424	40.9	4084	2239
1×400	3.4	37.6	4281	1916	42.8	5182	2817	44.6	5104	2739
1×500	3.4	41.1	5356	2320	46.7	6377	3341	48.1	6249	3213
1×630	3.4	45.0	6737	2828	50.8	7872	3963	54.6	8078	4169
1×800	3.4	49.1	8444	3441	55.1	9706	4703	57.7	9765	4762
1×1000	3.4	53.1	10243	4093	59.3	11630	5480	62.7	11795	5645
3×25	3.4	38.7	1859	一	44.6	2614	一	45.7	3479	一
3×35	3.4	41.3	2255	-	47.4	3067	一	48.3	3970	一
3×50	3.4	44.1	2719	1852	50.1	3569	2697	52.3	5021	4149
3×70	3.4	47.7	3454	2197	54.0	4392	3129	56.3	6002	4739
3×50	3.4	51.6	4330	2590	57.9	5338	3590	60.2	7045	5297
3×120	3.4	54.4	5140	2955	60.9	6197	4000	63.2	8017	5820
3×150	3.4	58.1	6055	3359	64.9	7238	4528	67.1	9130	6420
3× 185	3.4	61.9	7271	3907	68.6	8453	5072	70.9	10515	7134
3×240	3.4	67.3	9050	4647	74.4	10388	5962	76.5	12566	8140
3×300	3.4	72.7	10993	5457	79.7	12419	6855	82.1	14825	9261
3×400	3.4	78.5	13589	6494	87.1	15975	8845	89.6	18802	11672
3×500	3.4	86.2	17026	7917	95.7	19720	10566	97.5	22745	13591

Typus et nomen funis

Nomial transire- sectione transversali area mm2	Insulation crassitudine mm	YJV YJY YJLV YJLY			YJV22 YJV22YJLV23 YJLV23			YJV32 YJV32 YJLV32 YJLV32
		Proxime altiore diametri mm	Calculus pondus of* cable		Proxime altiore diametri mm	Calculus weight de fune		Proxime altiore diametri mm	Calculus weight of cable
		Proxime altiore diametri mm	YJV YJY	YJLV YJLY	Proxime altiore diametri mm	YJV22 YJV22	YJLV23 YJLV23	Proxime altiore diametri mm	YJLV23 YJLV23	YJLV32 YJLV32
1×25	4.5	21.4	639	-	25.4	947	-	27.4	1049	-
1×35	4.5	22.7	767	-	26.5	1080	-	28.7	1199	-
1×50	4.5	23.9	913	624	27.7	1241	952	29.9	1368	1079
1×70	4.5	25.7	1159	740	29.5	1510	1091	31.7	1644	1225
1×95	4.5	27.4	1440	860	31.4	1825	1245	33.4	1952	1372
1×120	4.5	28.8	1701	973	32.6	2092	1364	34.8	2235	1507
1×150	4.5	30.4	1995	1096	34.4	2419	1520	36.4	2554	1655
1×185	4.5	32.2	2377	1256	37.4	3156	2035	38.2	2968	1847
1×240	4.5	34.8	2964	1496	39.8	3783	2315	40.8	3600	2132
1×300	4.5	37.3	3594	1749	42.5	4488	2643	44.3	4406	2561
1×400	4.5	39.8	4420	2055	45.2	5392	3027	47.0	5304	2939
1×500	4.5	43.5	5526	2490	49.1	6604	3568	50.7	6481	3445
1×630	4.5	47.4	6921	3012	53.4	8139	4230	55.8	8166	4257
1×800	4.5	51.5	8643	3640	57.5	9963	4960	60.1	10015	5012
1×1000	4.5	55.3	10435	4285	61.5	11875	5725	64.1	11933	5783
3×25	4.5	43.9	2160	-	49.9	3024	-	51.1	4010	-
3×35	4.5	46.2	2551	-	52.3	3447	-	54.6	5003	-
3×50	4.5	49.0	3036	2164	55.3	3994	3122	57.6	5623	4751
3×70	4.5	52.9	3812	2549	59.4	4865	3602	61.5	6606	5343
3×50	4.5	56.8	4747	2999	63.2	5833	4085	65.6	7741	5993
3×120	4.5	59.6	5546	3349	66.2	6711	4514	68.6	8693	6496
3×150	4.5	63.2	6528	3818	70.1	7751	5041	72.2	9797	7087
3× 185	4.5	66.9	7728	4347	73.7	8985	5604	76.1	11206	7825
3×240	4.5	72.4	9574	5148	79.5	10954	6528	81.8	13322	8896
3×300	4.5	77.8	11572	6008	86.5	13880	8316	88.7	16685	11121
3×400	4.5	83.6	14281	7151	92.5	16704	9574	94.7	19671	12541
3×500	4.5	91.1	17640	8486	100.8	20456	11302	102.8	23644	14490

Type/Nomen Main use of 8030 series aluminium oflay cable with high conductivity

Type	Name	Pelagus usus
YJLHV	· aluminium mixturae nucleus crosslinked polyethylene insulatas polyvinyl chloride circumfusa potentia fune	· Poni potest in umbraticis non humidis, cuniculis et in subsidio fixis, salvis sumptum pontis vel fistulae.
YJLHY	· aluminium mixturae nucleus crosslinked polyethylene Nulla polyethylene circumfusa potentia funem	· Poni potest in siti vel humido ambitu, et auxilium sub tectis, bracket, scala vel funis fixtura adhiberi potest. Foris funis fossa, alveus iuxta canalem vel impositione defossus, maiorem vim externam mechanicam sustinere potest.
YJLHV22	· aluminium mixturae nucleus crosslinked polyethylene insulatas polyvinyl chloride exterius vaginatus ferro tape armatura funem potentia	· Stabilis et certa effectus, leve pondus, intus collocari, uncis fixum, in cuniculis, fistulis, fune sulcis et soli laxare, externam actionem mechanicam sustinere non possunt.
YJLHY23	· aluminium mixturae nucleus crosslinked polyethylene insulatas ferro tape armatura polyethylene exterius circumfusa potentia funem	· Stabilis et certa effectus, immediate sepeliri potest, quandam vim externam mechanicam sustinere potest, sed magnas contentiones sustinere non potest.
YJLHV32	· aluminium mixturae nucleus crosslinked polyethylene insulatas denique filum armatura polyvinyl chloride exterius circumfusa potentia funem	· Poni potest in arido vel humido ambitu, et adminiculo sub tectis, bracket, scala vel funis fixtura adhiberi potest. Foras funem fossa, cuniculo vel impositione sepulta dirigere potest, maiorem vim externam mechanicam sustinere potest.
YJLHY33	· aluminium mixturae nucleus crosslinked polyethylene insulatas denique filum armatae polyethylene exteriores circumfusa potentia funem	· Leve pondus, in arido vel humido ambitu collocari potest, umbraticis bracket, bracket, scalis vel funis fixa superficies adhiberi potest; Velis funem fossam, cuniculum vel impositionem sepultam dirigere possunt, maiorem vim externam mechanicam sustinere possunt. Praeclara flamma retardatio et ignis resistentia, usque ad genus A.

Nota: Iuxta ad mos requisita, flammae retardant gradus productio, flamma retardat B gradus flamma retardat C gradus seu aluminium mixturae funis, funis exemplar ante addit "ZA-, ZB- vel ZC(ZR) -"; Ut ZA-YJLHV, ZB-YJLHV22, ZC-YJLHY. Omnia genera halogenis liberorum fumi flammae retardant aluminium mixturae rudentes retardant, addito "WDZA -, WDZB - vel WDZR(ZC) -" ante exemplar funem. Si aluminium mixturae funis cum -40℃ relucentia temperatura humilis adhibeatur in locis cum temperatura ambiente nimis humilis, adde "(-40)" post exemplar productum..
